Characteristics |
|
Spectral range: |
380-780 nm |
|
Detection: |
Miniature fiber optic
spectrometer |
|
Light source: |
High-power tungsten halogen
(360-2000 nm) |
|
Sample collection: |
Fiber optic integrating sphere |
|
Color calculations: |
CIE
L*a*b*
color characteristics |
|
Measurement calibration: |
Manual calibration using known
filter standard (not included);
calibration time <30 seconds |
|
System calibration: |
Recommend annual recalibration |
|
Transmittance calibration
standards: |
Available |
|
Typical samples measured: |
Windows, filters, glass and
plastic lenses |
|
Sample size: |
10-150 mm diameter, up to 10 mm
thickness |
|
Optical stage: |
White powder-coated aluminum (optional black anodized
aluminum version available) |
|
Software: |
Customized lens transmittance
and color calculation software |
|
Quality: |
Calibration referenced to
accepted standards |
|
Manufacturing compliance: |
CE/UL/RoHS/WEEE |
|
|
|
Performance |
|
Transmittance measurement
accuracy: |
+/-1.0% |
|
Transmittance measurement
precision: |
+/-0.1% |
|
Data acquisition time: |
<5.0 seconds |
|
Light source output: |
20 watts |
|
Light source stability: |
0.5% (~15 minutes to stabilize) |
|
Light source drift: |
<0.3% per hour |
|
Bulb lifetime: |
2,000 hours |
|
Bulb color temperature: |
3,000 K |
|
Operating temperature: |
5°C - 35°C |
|
Operating humidity: |
5-95% at 40°C |
|
|
|
Computer & Power Requirements |
|
Operating systems: |
Windows Operating System |
|
Computer interfaces: |
USB 2.0 @ 480 Mbps |
|
Power requirements: |
100-240V, 50-60 Hz, 1.5A |
