| Dimensions: |
150 mm x 135 mm x 319 mm |
| Weight: |
5.35 kg (without power cord) |
| Power consumption |
830 mA @ 230 VDC or 1660 mA @ 115 VDC |
| Wavelength range: |
215-400 nm (standard bulb); 190-400 nm (deep-UV bulb) |
| Peak-to-peak stability: |
<0.005% at 250 nm |
| Drift: |
+/-0.5% per hour at 250 nm |
| Warm-up time: |
40 minutes |
| Voltage and current: |
Ignition 350V/20?operating 85 V/0.3A |
| Bulb lifetime: |
1,000 hours for standard or deep-UV bulb |
| Operating temperature: |
5 Celsius - 35 Celsius |
| Humidity: |
5-95% without condensation at 40 Celsius |
| Radiation characteristic: |
Aperture 0.5 mm, numerical aperture 26 Degree (13 Degree) |
| Power requirements: |
85-264 V 50/60 Hz |
| Markings: |
CE; VDI/VDE 0160; EN 61010 |
| TTL-shutter input: |
Up to 5 Hz maximum (shutter versions only) |
| Shutter speed: |
10 msec minimum |
